WS-C2960XR-48LPD-I Specification |
|
| Enclosure type | Rack-mountable – 1U |
| Ports | 48 x 10/100/1000 (POE+) + 2 x 10 Gigabit SFP+ |
| Network management Interface | 10/100 Mbps Ethernet (RJ-45) |
| Available PoE Power | 370W |
| Forwarding bandwidth(Gbps) | 108Gbps |
| Maximum stacking number | 8 |
| Stack Bandwidth | 80G |
| Forwarding Performance | 130.9Mpps |
| Switching bandwidth | 216Gbps |
| Maximum active VLANs | 1023 |
| MAC Address Table Size | 16K (default) |
| CPU | APM86392 600MHz dual core |
| RAM | 512 MB |
| Flash Memory | 128 MB |
| Status Indicators | ● Per-port status: Link integrity, disabled, activity, speed, and full duplex ● System status: System, RPS, PoE, Stack link status, link duplex, and link speed |
| Expansion / Connectivity | |
| Console ports | USB (Type-B), Ethernet (RJ-45) |
| Expansion Slot(s) | 1 FlexStack-Plus slot and 1 power redundant slot |
| Stack Modules | C2960X-STACK |
| Stacking cable | ● CAB-STK-E-0.5M FlexStack-Plus stacking cable with a 0.5 m length ● CAB-STK-E-1M FlexStack-Plus stacking cable with a 1.0 m length ● CAB-STK-E-3M FlexStack-Plus stacking cable with a 3.0 m length |
| Power supply | PWR-C2-250WAC |
| Power Device | Power supply – redundant – plug-in module |
| Power Redundancy | optional |
| Voltage range (Auto) | 110V-240V |
| Power Consumption Operational | 0.48kVA |
| Miscellaneous | |
| Width | 17.5 Inches (44.5 cm) |
| Depth | 16 Inches (40.8 cm) |
| Height | 1.75 Inches (4.45 cm) |
| Weight | 14.0 Pounds (6.4 Kg) |
| Rack Mounting Kit | Optional |
| MTBF in hours | 275,430 |
| Compliant Standards | ● IEEE 802.1D Spanning Tree Protocol ● IEEE 802.1p CoS Prioritization ● IEEE 802.1Q VLAN ● IEEE 802.1s ● IEEE 802.1w ● IEEE 802.1X ● IEEE 802.1ab (LLDP) ● IEEE 802.3ad ● IEEE 802.3af and IEEE 802.3at ● IEEE 802.3ah (100BASE-X single/multimode fiber only) ● IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports ● IEEE 802.3 10BASE-T ● IEEE 802.3u 100BASE-TX ● IEEE 802.3ab 1000BASE-T ● IEEE 802.3z 1000BASE-X ● RMON I and II standards ● SNMP v1, v2c, and v3 ● IEEE 802.3az ● IEEE 802.3ae 10Gigabit Ethernet ● IEEE 802.1ax |
